MSI GeForce RTX 5080 SHADOW 3X OC – 16GB

GPU

• Architecture: NVIDIA Blackwell (GB203‑400‑A1)
• Process: TSMC 4N, 5 nm
• CUDA Cores: 10,752
• Ray Tracing Cores: 84 (4th Gen)
• Tensor Cores: 336 (5th Gen)
• Base Clock: 2295 MHz
• Boost Clock: 2617–2640 MHz (OC)
• FP32 Performance: ~57.1 TFLOPS

Memory

• Capacity: 16 GB
• Type: GDDR7
• Bus Width: 256‑bit
• Effective Speed: 30 Gbps
• Bandwidth: 960 GB/s

Features

• DLSS: NVIDIA DLSS 4 with Multi‑Frame Generation
• Ray Tracing: Full neural rendering support
• AI Enhancements: NVIDIA ACE, Broadcast, Studio tools
• Latency Reduction: NVIDIA Reflex 2 with Frame Warp
• Encoding: 9th‑Gen NVIDIA Encoder

Connectivity

• Interface: PCIe 5.0 ×16
• Outputs: HDMI 2.1, DisplayPort 2.1
• Multi‑Monitor: Up to 4 displays

Cooling & Design

• Cooler: MSI SHADOW 3X triple‑fan design
• Form Factor: 2.5‑slot, reinforced backplate
• RGB: Mystic Light support

Package Contents

• Graphics Card × 1

• Accessory Kit (cables, brackets) × 1

• User Manual × 1
