Motherboard Specifications

• Model: MSI PRO Z890‑P WIFI
• Form Factor: ATX
• Chipset: Intel Z890
• CPU Support: Intel 14th/13th/12th Gen Core, Pentium Gold, Celeron (LGA 1700 socket)
• Memory:
  • 4 × DDR5 DIMM slots
  • Up to 256 GB capacity
  • Dual‑channel architecture
  • Supports XMP profiles

Expansion Slots

• PCIe x16: 1 × PCIe 5.0 x16 slot
• PCIe x1/x4: Multiple PCIe 4.0 slots for expansion

Storage

• M.2 Slots: 4 × M.2 Gen4/Gen5 slots (with heatsinks)
• SATA Ports: 6 × SATA 6 Gb/s

Networking

• LAN: 2.5G LAN (Realtek chipset)
• Wi‑Fi: Intel Wi‑Fi 7 module with Bluetooth 5.4

Audio

• Codec: Realtek ALC897/ALC1200 (depending on revision)
• Channels: 7.1 HD Audio

Rear I/O Ports

• USB:
  • 2 × USB 3.2 Gen2 Type‑A
  • 1 × USB 3.2 Gen2x2 Type‑C
  • 4 × USB 3.2 Gen1
  • 2 × USB 2.0
• Video Outputs: 1 × HDMI, 1 × DisplayPort
• LAN Port: 1 × RJ‑45 2.5G
• Wi‑Fi Antenna Connectors: 2 × SMA
• Audio Jacks: 5 × 3.5 mm + Optical S/PDIF

Internal Connectors

• Fan Headers: Multiple PWM/DC fan headers
• RGB Headers: 3 × ARGB (5 V), 2 × RGB (12 V)
• Front Panel USB: USB 3.2 Gen1, USB 3.2 Gen2 Type‑C

Physical

• Dimensions: Standard ATX (305 × 244 mm)
• Power Connectors: 24‑pin ATX + 8‑pin EPS + 4‑pin EPS

Package Contents

• Motherboard Unit × 1
• Wi‑Fi Antenna × 2
• SATA Cables × 2
• M.2 Screws & Standoffs × 1 set
• User Manual × 1
• Driver/Utility DVD or USB × 1
• Warranty Information × 1
