Switch Specifications

• Model: TP‑Link TL‑SG1016D V9
• Type: Gigabit Desktop/Rackmount Switch
• Ports: 16 × 10/100/1000 Mbps RJ‑45 ports
• Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x
• Switching Capacity: 32 Gbps
• Packet Forwarding Rate: 23.8 Mpps
• MAC Address Table: 8K entries
• Buffer Memory: 3.2 Mb

Features

• Plug & Play: No configuration required
• Flow Control: IEEE 802.3x full‑duplex, backpressure half‑duplex
• Green Technology: Energy‑efficient Ethernet (EEE)
• Fanless Design: Silent operation
• Housing: Metal case for durability
• Mounting Options: Desktop or rackmount

Physical

• Dimensions (W × D × H): 294 × 180 × 44 mm
• Weight: ~1.3 kg
• Mounting: Rackmount kit included

Power

• Power Supply: External adapter, 9 VDC/1 A
• Power Consumption: Max ~14.2 W

Package Contents

• TL‑SG1016D V9 Switch × 1
• Power Adapter × 1
• Rackmount Kit × 1
• Quick Installation Guide × 1
• Warranty Information × 1
