Design & Build

Color: Black
Case Type: Mid Tower
Side Panel: Curved tempered glass (aquarium style)
Front Panel: Tempered glass with ARGB lighting
Secondary Display: 9″ LCD panel (1920 × 462 resolution, HDMI + USB powered, optional)
Lighting: Dynamic ARGB LED lighting
Airflow Design: Optimized ventilation with multiple intake/exhaust options

Motherboard Support

Form Factors: E‑ATX (≤285 mm), ATX, Micro‑ATX (back‑plug supported), ITX

Cooling Support

Front Radiator: Up to 360 mm
Top Radiator: Up to 360 mm
Rear Radiator: 120 mm
Pre‑Installed Fans: 3 × ARGB fans (front)
Additional Fan Support: Multiple mounting positions

Storage

Drive Bays: 2 × 3.5″ HDD, 2 × 2.5″ SSD

Clearances

GPU Length: Up to 400 mm
CPU Cooler Height: Up to 170 mm
PSU Length: Up to 200 mm

Dimensions

Length × Width × Height: 460 × 230 × 490 mm (approx.)
Weight: ~9.5 kg

Package Contents

Xigmatek Pano II Black Case × 1
Pre‑Installed ARGB Fans × 3
Accessory Kit (screws, mounts) × 1
User Manual × 1
